3 Way Wing Type Unistrut Angle Connector Fittings 90 Degree Strut Channel Joint Bracket
Introduction
Our 3 Way Wing Type Unistrut Angle Connector Fittings are special multi-directional connecting brackets designed for three-dimensional strut channel frame construction. Different from ordinary two-dimensional right-angle brackets, this wing-type three-way angle fitting supports three-direction channel connection at the same time, realizing three-dimensional frame cross assembly. The unique wing-type structure is scientifically designed with reasonable stress distribution, which can stably fix horizontal, vertical and lateral strut channels to form a stable three-dimensional support frame. Made of thickened high-strength carbon steel, the product has strong bearing capacity and structural stability, not easy to deform under multi-directional stress. The surface is treated with high-quality galvanization to resist oxidation and corrosion, adapting to various complex installation environments. Precision punching ensures that each hole position is accurately matched with standard accessories, realizing fast three-dimensional assembly without welding. Widely used in three-dimensional equipment racks, multi-layer pipeline support, space frame construction and three-dimensional seismic support systems, this three-way wing angle fitting greatly simplifies the construction process of complex three-dimensional frames and improves the integration degree of the support system.
Features
The innovative 3-way wing-type structure breaks through the limitation of traditional two-dimensional connection, realizing three-dimensional multi-directional synchronous connection of strut channels. Scientific wing body force design ensures uniform stress in all directions, avoiding local stress concentration and structural damage. Thickened steel plate enhances the overall load-bearing capacity and structural toughness, adapting to complex three-dimensional frame load scenarios. The galvanized protective layer has excellent anti-corrosion performance, ensuring long-term stable use of the product. Precision hole position calibration ensures smooth assembly and good compatibility with standard accessories. It simplifies the construction of complex three-dimensional frames, reduces the use of auxiliary accessories, and improves the overall structural integration and aesthetics. It is a special high-efficiency connecting accessory for space three-dimensional strut channel support systems.
Specification
|
Item
|
Technical Specification
|
|---|---|
|
Product Name
|
Unistrut Angle Fittings, Strut Channel Corner Bracket, L-type Angle Connector, 3-Way Wing Angle Fittings
|
|
Applicable Channel
|
41x21mm, 41x41mm Standard Strut Channel, BTB Back-to-Back Strut Channel
|
|
Angle Style
|
90 Degree Right Angle, L Shape, Flat Gusset Plate, 3-Way Multi-directional Type
|
|
Hole Design
|
2 Holes, 4 Holes, 8 Holes, Multi-hole Adjustable, Custom Punching Available
|
|
Plate Thickness
|
2.0mm, 2.5mm, 3.0mm, Thickened Heavy Duty Type, Custom Thickness
|
|
Raw Material
|
Q235B Carbon Steel, Q355 High Strength Steel, SUS304 Stainless Steel, SUS316 Stainless Steel
|
|
Surface Treatment
|
Hot Dip Galvanized(HDG), Pre-Galvanized(GI), Electro-galvanized, Stainless Steel Polished
|
|
Zinc Coating Thickness
|
Electro-galvanized: 8-12μm; Pre-galvanized: 15-25μm; HDG: 60-85μm
|
|
Manufacturing Process
|
Integral One-piece Stamping Forming, No Weld Gap, High Flatness
|
|
Dimensional Tolerance
|
±0.3mm High Precision Dimension & Hole Position Control
|
|
Performance Features
|
Heavy Load Bearing, Anti-deformation, Anti-corrosion, Vibration Resistant, Easy Installation, Reusable
|
|
Application Scenarios
|
Solar Mounting System, HVAC Duct Support, Industrial Pipe Support, Construction Framing, Seismic Bracing, Electrical Equipment Fixing
|
|
Custom Service
|
OEM, ODM, Custom Size, Custom Hole Spacing, Custom Thickness, Custom Logo
|
|
Stock Status
|
Standard Sizes In Stock, Custom Sizes Support Production
|
|
MOQ
|
Small Trial Order Acceptable, Bulk Order Supported
|
|
Packaging
|
Export Standard Carton + Wooden Pallet, Anti-rust & Anti-collision
|
|
Delivery Time
|
3-7 Days for Stock Items; 12-20 Working Days for Custom Orders
|
